Cryptologists Cook Up Some Hash for New 'Bake-Off'
A worldwide competition aims to keep the algorithms for
authenticating electronic documents a jump ahead of forgers' ability to
In November, three Dutch cryptologists published on their Web site a
"digital fingerprint" of their prediction of the winner of the United
States's 2008 presidential election. According to them, the next
commander in chief will be 3D515DEAD7AA16560ABA3E9DF05 CBC80.
After the election, these modern-day Nostradamuses will use a simple
mathematical procedure called a hash function, which is available on
nearly all computers, to show that a PDF document created before the
election has that hexadecimal number as its digital fingerprint. This
will prove that they knew the winner all along, because the PDF
document could not have been altered after the election. Any such
change would make its fingerprint, known as a hash value, no longer
match the one that has been published.
But it's all a trick. The "Nostradamus attack" by Marc Stevens, Arjen
Lenstra, and Benne de Weger is designed to highlight a serious problem
in cryptology: The so-called hash functions that many of the world's
computers use for authenticating documents are dangerously out of date.
The cryptologists prepared 12 separate documents, one saying that John
McCain will win, one naming Hillary Clinton, and one even predicting
Paris Hilton. By carefully tweaking the contents of each PDF document,
in a way not obviously noticeable, they made it so each one generates
the same digital fingerprint, computed by a widely used hash function
called MD5. As the Dutch effort shows, the ability to produce multiple
documents with the same fingerprint renders MD5 useless for
Without the ability to authenticate files, such as passwords and online
transactions, Internet commerce would be seriously threatened.
Therefore, the U.S. National Institute of Standards and Technology
(NIST) in November announced a worldwide competition to select a new
standard for hash functions, which is expected to conclude by 2012. The
winner will be certified for U.S. government use, and if past history
is any guide, that will make it a de facto standard for the rest of the
NIST held a similar "bake-off " (as some cryptologists called it) from
1997 to 2000 to select a new standard cipher for government use, called
the Advanced Encryption Standard (AES). "The AES competition was the
most fun I've ever had in cryptography," says Bruce Schneier of BT
Counterpane in Santa Clara, California, who designed one of the five
AES finalists and who plans to enter the hash-function competition as
well. "Think of it as a giant cryptographic demolition derby: A bunch
of us put our best work into the ring, and then we beat on each other
until there was only one standing. … I personally learned an enormous
amount about [cipher design] from the AES competition, and we as a
community benefited immeasurably."
Like the previous competition, the new bake-off offers no financial
reward, and the submissions must be unpatented so that they can be
incorporated into any software. The real payoff to the winner will be
prestige. The AES competition drew 15 entries, and the hash-function
competition is expected to attract as many as 50.
Although the contests will be similar, the products could hardly be
more different. A cipher, like AES, encrypts data in such a way that it
can be recovered but only by someone with a key. Hash functions, on the
other hand, are not meant to be reversible, and they have no secret
key. They merely show that a document is what it claims to be. They
tend to be much simpler than ciphers and have a much broader range of
applications--so many that they are often called the "duct tape" or
"Swiss army knife" of cryptology.
Hash functions work by converting any string or message of 1s and 0s to
a new string, usually much shorter. For example, the function might
take a gigabyte MPEG movie file and boil it down to anywhere from 128
to 512 bits. In the current government standard, called SHA-1, the
output, known as the hash, hash value, or hash sum, is 160 bits,
whereas for MD5 it is 128 bits. The hash should look more or less
random so that no one can guess what the original message said. On the
other hand, it should be generated in a completely deterministic manner
so that anybody who knows the hash function used can have a computer
verify that the hash value matches the hashed file's contents. In
addition, it should be staggeringly unlikely that any other document
hashes to the same value. When that happens, cryptographers call it a
Compressing gigabyte-sized files to 160 bits inevitably results in many
collisions. But the key point is that it is virtually impossible to
find one by random search. That is because there are so many possible
of them for a 160-bit hash sum. For such a hash value, the number of
movies you would have to hash before generating the same hash twice
would be roughly 280, or a trillion a year for a billion years. Not even Bollywood is that prolific.
However, a hash function can be defeated if it is possible to
deliberately create two colliding documents. If this takes more than 280
attempts, then the hash function is considered secure, because such an
attack is no better than random guessing. However, if a collision can
be found in less than 264 tries, then a supercomputer, or a
very large network of personal computers, might be able to do it in a
year. If it takes less than 232 tries, one can do it on a PlayStation in a few minutes--as the Dutch "Nostradamuses" did.
The current standard, SHA-1, borrows its basic architecture from MD5,
which was invented in 1992. You feed your message into a device that
compresses and randomizes 512 bits at a time. You add another piece of
your file to the first piece and feed it through again, and you repeat
this procedure until you run out of message.
Iterative algorithms, like MD5 and SHA-1, are very easy to program and
quick to run. But recently, they have come under heavy attack from
cryptologists. In 2004 and 2005, cryptologist Xiaoyun Wang of Shandong
University in China showed that MD5 could be cracked in fewer than 240 steps, and SHA-1 in fewer than 264.
No one has produced an actual collision in SHA-1, but a search, using
the spare time of many personal computers, is under way at Graz
University of Technology in Austria.
"If you find a [SHA-1] collision, people in industry will be forced to
upgrade their products," says Bart Preneel, a cryptologist at
Katholieke Universiteit Leuven in Belgium. Anticipating such a
breakdown, Microsoft in 2005 banned both SHA-1 and MD5 from new
products and has removed MD5 from all its current products, says
Kristin Lauter, head of the Cryptography Group at Microsoft Research in
Redmond, Washington. Fortunately, a good backup is already available.
In 2004, NIST issued several new standards, collectively called SHA-2,
which are more secure than SHA-1 because they produce longer hashes (up
to 512 bits instead of 160).
But NIST worries that SHA-2 could eventually fall, too. "Everything
that has been attacked is in the same family," says William Burr of
NIST's Security Technology Group. "It may turn out that they aren't
broken or can't be broken, but we didn't want to get caught out on the
After extensive debate, including two international workshops in 2005
and 2006, NIST decided that a new competition could turn up completely
new approaches to hash functions. "We'll be reluctant to pick something
that looks just like SHA-2," says Burr. "We want some biodiversity."
Although no designs have been formally submitted yet--the deadline is
in October--experts predict that most entrants will continue to be
iterative algorithms subtly retooled to defeat the new kinds of
attacks. For instance, Preneel's RIPEMD--one of the few
first-generation hash functions still standing--performs two parallel
iterations, making it difficult for an attacker to figure out which one
A second approach, called "provably secure" hash functions, derives its
presumptive security from math problems that are considered to be hard
to crack (see sidebar, above). This type of algorithm typically does
not require multiple iterations, but it does require cryptologists to
put their faith in a mathematical "black box." Also, such algorithms
tend to be slower than iterative algorithms because they require a more
elaborate calculation--even though it is performed only once. Speed is
at a premium for hash functions, as they are typically used to tag a
document in the split-second it's electronically transmitted.
Not surprisingly, mathematicians love provably secure systems, whereas
cryptologists have little use for them. "They are typically only
provable with respect to one property but are weak with respect to
other properties," says Joan Daemen of STMicroelectronics, co-winner of
the AES competition. For instance, a "provably secure" hash developed
by Lenstra and his colleagues, called Very Smooth Hash (VSH), was
compromised last year when Markku-Juhani Saarinen at a Spanish company
called Kinamik showed that it was easy to find "near-collisions" in
VSH. In practice, engineers often truncate a long hash value to a
shorter one, assuming that the truncated hash will inherit the long
one's security. Saarinen's result means that they can't count on that
In the final analysis, what makes it so hard to come up with good hash
functions-- and prove they work--is that they are expected to do so
many things. "You expect them to do everything and blame them when they
don't work," says Preneel. Perhaps a 4-year bake-off will be just what
the chef ordered to make some new hash that will satisfy everybody's
Dana Mackenzie is a freelance writer in Santa Cruz, California.
